ZH-FM11 1+1 panel ONU

Host * 1 Provide 1 GPON/EPON adaptive PON optical port uplink 1 GE port (10/100/1000M adaptive) 1 POETS telephone interface Power Supply: AC220V Power consumption: ≤ 7W Physical dimensions: 86*86*30mm Working environment: 0 ° C to 60 ° C; 10% to 85% non condensing Including XOS system software V1.0
ZH-FM12 双口面板ONU

Host * 1 Provide 1 GPON/EPON adaptive PON optical port uplink 2 GE ports (10/100/1000M adaptive) Power Supply: AC220V Power consumption: ≤ 7W Physical dimensions: 86*86*30mm Working environment: 0 ° C to 60 ° C; 10% to 85% non condensing Including XOS system software V1.0
ZH-MA8500X2 Frame type OLT optical access central equipment

MA8500 series plug-in fiber optic server OLT Backplane bandwidth: 1.28T* Packet forwarding rate: 952.32Mpps MAC address capacity: 128K Standard fan board 1 power slot (standard includes AC+DC power supply) 2 main control slots* 2 business slots* Working environment: -20 ℃ to 65 ℃; 10% to 85% non condensing Input voltage: AC100～240V，DC 36～72V Supports dual power input (AC+DC) Typical power consumption: 280W Exterior dimensions (mm): 482.6 * 270 * 88.9mm 19 inches wide, 2U high Weight: Fully equipped 12 kg, empty frame 4.5 kg EAAS Cloud Unified Cloud Management Including XOS system software V1.0 Final assembly chassis * 1 Standard fan board * 1 AC+DC integrated power module * 1 Power cord * 1 1 set of hanging ears Certificate of conformity * 1 Product manual * 1
ZH-MA8500-MPSA MA5800X2 main control board -4 * 10GE+2 * 100GE

Main control board, 4 * GE/10GE+2 * 100G uplink (ZH-MA8500X2 dedicated)
ZH-MA8500-GP16A MA5800X2 business board -16 port GPON

GPON business board, 16 ports (ZH-MA8500X2 dedicated)
ZH-MA8500-CS16A MA8500X2 business version -16 port XG (S) PON&GPON the third mock examination

16 port, XG (S) PON&GPON the third mock examination COMBO service board (dedicated to ZH-MA8500X2)
ZH-MA8500X8 Frame type OLT optical access central equipment

MA8500 series plug-in fiber optic server OLT Backplane bandwidth: 7.2T* MAC address capacity: 710K Standard fan board 2 power slots (standard without power supply) 2 main control slots* 8 business slots* Working environment: -5 ℃ to 45 ℃; 10% to 85% non condensing Power supply mode:- 40V DC to -60V DC Supports dual power input and hot swappable power module Typical power consumption: 734W Appearance dimensions (mm): 482.6x289x310 (including cable tray), 482.6x286x310 (excluding cable tray) 19 inches wide, 7U high Weight: Full weight 28kg, empty frame 11.5kg Including XOS system software V1.0 Final assembly chassis * 1 Standard fan board * 1 1 set of hanging ears Certificate of conformity * 1 Product manual * 1
ZH-MA8500X15 Frame type OLT optical access central equipment

MA8500 series plug-in fiber optic server OLT Backplane bandwidth: 7.2T* MAC address capacity: 710K Standard fan board 2 power slots (standard without power supply) 2 main control slots* 15 business slots* Working environment: -5 ℃ to 45 ℃; 10% to 85% non condensing Power supply mode:- 40V DC to -60V DC Supports dual power input and hot swappable power module Typical power consumption: 1143W Appearance dimensions (mm): 482.6x286x576 (including cable tray), 482.6x286x486 (excluding cable tray) 19 inches wide, 11U high Weight: Fully equipped 44kg, empty frame 18.5kg Including XOS system software V1.0 Final assembly chassis * 1 Standard fan board * 1 1 set of hanging ears Certificate of conformity * 1 Product manual * 1
ZH-MA8500-CSM3S Main control board (ZH-MA8500X8/X15 dedicated)

Main control board, 7.2 Tbps, 4 * 25GE/10GE upstream (ZH-MA8500X8/X15 dedicated)
ZH-MA8500-PDC1A DC power board (ZH-MA8500X8/X15 dedicated)

DC power board (ZH-MA8500X8/X15 dedicated)
ZH-PWR-AC/DC ZH-PWR-AC/DC

External power supply (220v to 48v), national standard
ZH-MA8500-XUC1A Upboard -8 ports 25GE/10GE/GE

25GE/10GE/GE uplink board, 8-port (ZH-MA8500X8/X15 dedicated)
